The Teranex Mini IP Video 12G is a high-performance video converter designed for professional broadcast, live production, and AV integration applications. Developed by Blackmagic Design, it supports SD, HD, and Ultra HD video formats up to 2160p60, delivering exceptional image quality, ultra-low latency, and reliable signal conversion for demanding production environments.

Key FeaturesMulti-Rate 12G-SDI Processing

The Teranex Mini IP Video 12G supports 12G-SDI multi-rate technology, automatically detecting and switching between SD, HD, 3G-SDI, 6G-SDI, and Ultra HD (2160p60) video standards. A single BNC cable is all that's required to transport high-bandwidth Ultra HD video, simplifying installation while reducing infrastructure costs.

Professional 12-Bit Video Processing

Built with Blackmagic's renowned video processing technology, the converter delivers 12-bit image processing, SDI re-clocking, and low-jitter signal transmission, ensuring broadcast-quality video with outstanding stability and accuracy.

Integrated LCD Control Panel

An integrated LCD display allows operators to monitor incoming and outgoing video signals, review device status, and adjust system settings directly from the front panel without requiring a computer.

Optional intelligent front panel controls make on-site configuration faster and more convenient, particularly in live production environments.

Flexible Rack-Mount Design

The compact Teranex Mini can operate as a standalone desktop converter or be installed in a professional rack system. Its modular design makes it ideal for:

• Television studios
• Broadcast control rooms
• OB vans (Outside Broadcast Vehicles)
• Live event production
• Mobile production racks
• Corporate AV installations

Remote Management via Ethernet

Integrated Ethernet connectivity enables centralized remote management of multiple Teranex Mini units using Blackmagic Converter Utility software for both Windows and macOS.

The Ethernet interface also supports Power over Ethernet (PoE), reducing cable requirements and simplifying installation.

Professional Audio Connectivity

The converter features full-size XLR audio connections, supporting both balanced analog audio and AES/EBU digital audio. This allows seamless integration with:

• Professional audio mixers
• Audio processors
• Broadcast routing systems
• SDI production equipment
• Digital audio infrastructure

Ultra-low noise circuitry (below –115 dBFS) ensures outstanding audio performance for professional broadcasting and production.

Intelligent Cooling System

An advanced Crossflow cooling system with integrated heat-pipe technology provides efficient thermal management while maintaining extremely low operating noise.

The converter continuously monitors its internal temperature and provides overheating notifications through both the front-panel display and remote Ethernet management software, ensuring maximum operational reliability.

Applications

The Teranex Mini IP Video 12G is ideal for a wide range of professional applications, including:

• Television broadcasting
• Live streaming production
• Professional video production
• Post-production and color grading
• Corporate AV systems
• Conference and event venues
• LED display systems
• Projection systems
• Broadcast control rooms
• Outside Broadcast (OB) vehicles
• IP-based video infrastructures
